INSTRUMENT PANEL COMPONENT LOCATION

2.0 16V JTD, 2.2 16V JTD · MY 2005

Component code	Description	Reference to the assembly
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
C010	LEFT FRONT EARTH
C011	RIGHT FRONT EARTH
C020	PASSENGER SIDE DASHBOARD EARTH
D070	DRIVER''S SEAT COUPLING
D213	FUEL TANK COUPLING
E050	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	Ignition switch	Op. 5520A IGNITION SWITCH
I040	HANDBRAKE APPLIED SWITCH	Op. 5550D BRAKE AND REVERSING LIGHTS
I046	DRIVER''S SEAT BELT SWITCH
K020	LEFT BRAKE PAD WEAR SENSOR (SWITCH)	Op. 3310A FRONT DISC BRAKES
K021	RIGHT BRAKE PAD WEAR SENSOR (SWITCH)	Op. 3310A FRONT DISC BRAKES
K025	BRAKE FLUID LEVEL SENSOR (SWITCH)
K026	Engine coolant level sensor
K030	INSUFFICIENT ENGINE OIL PRESSURE SENSOR	Op. 1084A INDICATORS/CHECK DEVICES
K032	ENGINE OIL LEVEL SENSOR	Op. 1084A INDICATORS/CHECK DEVICES
K036	ENGINE COOLANT TEMPERATURE SENSOR/SENDER UNIT	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M010	ENGINE MANAGEMENT CONTROL UNIT	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
M050	ABS CONTROL UNIT	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
M060	AIR BAG CONTROL UNIT	Op. 5580C AIR BAG SYSTEM
M140	WARNING LIGHTS AND MILOMETER CONTROL UNIT (NSO)
M172	MULTIFUNCTION SCREEN NODE
N040	FUEL PUMP AND LEVEL GAUGE	Op. 1040A FUEL TANK AND COMPONENTS
