NAVIGATOR COMPONENT LOCATION

2.0 16V JTD, 2.2 16V JTD · MY 2005

Component code	Description	Reference to the assembly
B001	ENGINE COMPARTMENT JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
C020	PASSENGER SIDE DASHBOARD EARTH
C022	Centre dashboard earth
D020	DASHBOARD/REAR COUPLING
D030	DRIVER''S FRONT DOOR COUPLING
D031	PASSENGER FRONT DOOR COUPLING
D042	COURTESY LIGHT COUPLING
D055	Dashboard/TV coupling
E050	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M140	WARNING LIGHTS AND MILOMETER CONTROL UNIT (NSO)
M160	CONNECT CONTROL PANEL
M172	MULTIFUNCTION SCREEN NODE
N160	CONNECT COOLING FAN	Op. 5580P CONNECT PANEL
P020	RADIO
P022	AERIAL AND HEATED REAR WINDOW CONTROL UNIT
P025	AERIAL FEED/AMPLIFIER
P027	MICROTELEPHONE
P035	SPEAKER IN LEFT FRONT DOOR	Op. 5570T CAR RADIO AND CAR TELEPHONE
P036	SPEAKER IN RIGHT FRONT DOOR	Op. 5570T CAR RADIO AND CAR TELEPHONE
P045	LEFT FRONT TWEETER SPEAKER	Op. 5570T CAR RADIO AND CAR TELEPHONE
P046	RIGHT FRONT TWEETER SPEAKER	Op. 5570T CAR RADIO AND CAR TELEPHONE
P047	LEFT REAR TWEETER SPEAKER	Op. 5570T CAR RADIO AND CAR TELEPHONE
P048	RIGHT REAR TWEETER SPEAKER	Op. 5570T CAR RADIO AND CAR TELEPHONE
P075	CD CHANGER MODULE
P110	GPS/GSM AERIAL	Op. 5570T CAR RADIO AND CAR TELEPHONE
P120	LEAF REAR SPEAKER IN SIDE PANEL
P121	RIGHT REAR SPEAKER IN SIDE PANEL
