Wiring diagrams and electrical functions Instrument panel location components
INSTRUMENT PANEL LOCATION COMPONENTS
2.4 20V
Location Components
Components
Component code Name Assembly reference B001 Engine compartment junction unit 5505A B002 Junction unit under dashboard B045 Luggage compartment junction unit (CVB) 5505A C010 Left front earth C015 Driver''s dashboard earth C022 Centre dashboard earth C030 Left rear earth D004 Giunzione anteriore / motore E050 Instrument panel H001 Ignition switch I050 Inertia switch 1040A K020 Left brake pad wear sensor (switch) K021 Right brake pad wear sensor (switch) K025 K030 K032 K045 I.E. engine temperature sensor 1056B K046 M001 Body computer M010 Engine management control unit 1056B M051 Braking system control unit (NFR) M063 Luggage compartment control unit (NVB) N040 1040A
2.4 JTD 20V · Automatic Transmission
Location Components
Components
Component code Name Assembly reference B001 Engine compartment junction unit 5505A B002 Junction unit under dashboard C010 Left front earth C011 Right front earth C012 C015 Driver''s dashboard earth C022 Centre dashboard earth C030 Left rear earth D004 Giunzione anteriore / motore E050 Instrument panel H001 Ignition switch K020 Left brake pad wear sensor (switch) K021 Right brake pad wear sensor (switch) K025 K030 K032 K036 K046 L050 Automatic transmission solenoid valves 2130B M001 Body computer M010 Engine management control unit 1056B M051 Braking system control unit (NFR) M055 Automatic transmission control unit M063 Luggage compartment control unit (NVB) N040 Fuel pump and level gauge
2.0 TB
Location Components
Components
Component code Name Assembly reference B001 Engine compartment junction unit 5505A B002 Junction unit under dashboard C010 Left front earth C012 C022 Centre dashboard earth D004 Giunzione anteriore / motore E050 Instrument panel H001 Ignition switch K025 K030 K032 K045 I.E. engine temperature sensor K046 M001 Body computer M010 Engine management control unit 1056B M051 Braking system control unit (NFR) N040 1040A
2.4 20V, 3.0 V6, 3.2 V6 · Automatic Transmission
Location Components
Components
Component code Name Assembly reference B001 Engine compartment junction unit 5505A B002 Junction unit under dashboard C010 Left front earth C011 Right front earth C012 C015 Driver''s dashboard earth C022 Centre dashboard earth C030 Left rear earth C040 D004 Giunzione anteriore / motore D029 Engine cables/engine services cable coupling E050 Instrument panel H001 Ignition switch K020 Left brake pad wear sensor (switch) K021 Right brake pad wear sensor (switch) K025 K030 Switch for engine oil pressure warning light K032 K036 Engine coolant temperature sensor/sender unit K046 L050 Automatic transmission solenoid valves M001 Body computer M010 Engine management control unit 1056B M051 Braking system control unit (NFR) M055 Automatic transmission control unit M063 Luggage compartment control unit (NVB) N040 Fuel pump and level gauge
2.4 JTD 10V
Location Components
Components
Component code Name Assembly reference B001 Engine compartment junction unit 5505A B002 Junction unit under dashboard B045 Luggage compartment junction unit (CVB) 5505A C010 Left front earth C012 C015 Driver''s dashboard earth C022 Centre dashboard earth C030 Left rear earth C040 D004 Giunzione anteriore / motore E050 Instrument panel H001 Ignition switch I050 Inertia switch 1040A K020 Left brake pad wear sensor (switch) K021 Right brake pad wear sensor (switch) K025 K030 K031 Water in diesel filter sensor K032 K045 I.E. engine temperature sensor 1056B K046 M001 Body computer M010 Engine management control unit 1056B M051 Braking system control unit (NFR) M063 Luggage compartment control unit (NVB) N040 1040A
19 Electrical
