Navigator location components
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Instrument panel › Navigator location components
Wiring diagrams and electrical functionsNavigator location components
NAVIGATOR LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C012 | ||
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| D020 | ||
| D047 | ||
| D097 | Short circuit coupling | |
| D110 | CLOCK SPRING AND STEERING WHEEL CONTROLS COUPLING | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| M001 | Body computer | |
| M051 | Braking system control unit (NFR) | |
| M062 | 7040E | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M093 | STEERING WHEEL NODE CONTROL UNIT (NVO) | |
| P110 |
