Wiring diagrams and electrical functionsTv tuner location components
TV TUNER LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C012 | ||
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| C030 | Left rear earth | |
| C059 | TV diversity earth | |
| C070 | TV tuner earth | |
| D020 | ||
| D055 | ||
| D097 | Short circuit coupling | |
| H001 | Ignition switch | |
| M001 | Body computer | |
| M051 | Braking system control unit (NFR) | |
| M062 | 7040E | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M100 | TV tuner |
