TD5 Defender
10
MAINTENANCE
12
MAINTENANCE
AUXILIARY DRIVE BELT
Check
1. Check auxiliary drive belt for signs of splits,
fraying, oil contamination and wear.
NOTE: Any requirement to replace the
auxiliary drive belt should be advised to
the customer as this will incur additional
labour and/or material cost and should not be
carried out without the authorisation of the
customer.
Renew
1. Renew auxiliary drive belt. See ELECTRICAL,
Repair.
NOTE: Additional time is built into the
96,000/8 year service time to allow for
auxiliary drive belt renewal.
PAS FLUID, CLUTCH FLUID AND SCREEN
WASHER LEVELS
PAS Fluid
1. Clean arear around PAS reservoir filler cap, and
remove cap.
2. Check fluid level in PAS reservoir.
3. Top-up if necessary to the correct level using
recommended fluid. See LUBRICANTS,
FLUIDS AND CAPACITIES, Information.
4. Fit filler cap.
