Discovery II
CHARGING AND STARTING
86-1-4
REPAIRS
Belt - auxiliary drive
$% 86.10.03
Remove
1. Remove viscous fan:
l
l
2. Turn drive belt tensioner using a 15 mm ring
spanner and release belt from pulleys.
Refit
1. Clean drive belt pulley grooves and ensure
grooves are not damaged.
2. Fit new drive belt around pulleys, ensure belt is
correctly aligned in pulley grooves.
3. With assistance, hold tensioner fully clockwise
and fit drive belt around remaining pulley.
Release tensioner.
4. Fit viscous fan:
l
l
Battery
$% 86.15.01
Remove
1. Release fixings and remove battery cover.
2. Disconnect both battery leads, negative lead
first.
3. Remove lock nuts and retaining nuts securing
battery clamp.
4. Remove battery clamp.
5. Remove battery.
Refit
1. Clean battery terminals and coat with
petroleum jelly.
2. Fit battery.
3. Fit battery clamp and tighten retaining nuts and
lock nuts.
4. Fit both battery leads, negative lead last.
5. Fit battery cover and secure fixings.
