Discovery II
ENGINE MANAGEMENT SYSTEM - V8
ADJUSTMENTS 18-2-77
ADJUSTMENTS
Cable - throttle
$% 19.20.05
Adjust
1. Loosen outer cable locknuts.
2. Adjust the rear locknut until it is in contact with
the back of the abutment bracket, and the gap
between the throttle and the inner driven lever
is 0.5 mm
±
0.4 mm (0.020
±
0.015 in).
3. Tighten cable front nut to lock cable to
abutment bracket.
Cable - cruise control
$% 19.75.11
Adjust
1. Ensure that the throttle cable is correctly
V8, ADJUSTMENTS, Cable - throttle.
2. Loosen outer cable locknuts.
3. Adjust the rear locknut to obtain a 4.0 to 4.5
mm (0.157 to 0.177 in) gap, dimension 'A',
between the cruise control cable lever and the
throttle cable driven lever.
4. Tighten cable front locknut.
