Discovery II
FRONT SUSPENSION
ADJUSTMENTS
60-25
ADJUSTMENTS
ACE hydraulic system bleeding
$% 60.60.13
Introduction
CAUTION: The ACE hydraulic system is
extremely sensitive to the ingress of dirt or
debris. The smallest amount could render the
system unserviceable. It is imperative that the
following precautions are taken.
l
ACE components are thoroughly cleaned
externally before work commences;
l
all opened pipe and module ports are
capped immediately;
l
all fluid is stored in and administered
through clean containers.
Check
1. Check the ACE system fluid level.
ADJUSTMENTS, Fluid level check - ACE
system.
Bleed
1. With vehicle on ramp, connect TestBook and
follow bleed procedure as described.
Fluid level check - ACE system
$% 60.60.14
Introduction
CAUTION: The ACE hydraulic system is
extremely sensitive to the ingress of dirt or
debris. The smallest amount could render the
system unserviceable. It is imperative that the
following precautions are taken.
l
ACE components are thoroughly cleaned
externally before work commences;
l
all opened pipe and module ports are
capped immediately;
l
all fluid is stored in and administered
through clean containers.
Check
1. Clean reservoir around fluid level marks.
2. Visually check fluid level through side of
reservoir. Fluid level must be between upper
and lower fluid level marks.
Top-up
1. Clean reservoir around filler cap.
2. Remove filler cap from reservoir and fill to
upper fluid level mark with recommended fluid.
LUBRICANTS AND SEALANTS, Fluids.
3. Fit filler cap to reservoir
4. Start and run engine for 2 minutes to circulate
fluid.
5. If necessary, top-up reservoir to upper fluid
level mark.
