LR3/Disco 3
25 .
CAUTION: If power steering fluid comes into contact with the paintwork, the affected area
must be immediately washed down with cold water.
Disconnect the power steering pump supply hose.
Clamp the power steering pump supply hose to minimise fluid loss.
Install blanking caps to the exposed ports.
26 .
Remove the fuel filter.
Position a container to collect the fluid spillage.
Disconnect the four fuel lines.
Remove the two support bracket retaining bolts.
27 .
Remove the exhaust system. For additional information, refer to
Exhaust System (30.10.08)
(Section 309-00)
28 .
Install the crossmember.
Install the four nuts and bolts.
