Range Rover P38
01
INTRODUCTION
NEW RANGE ROVER
8
INFORMATION
JUMP STARTING
WARNING: Hydrogen and oxygen gases
are produced during normal battery
operation. This gas mixture can explode if
flames, sparks or lighted tobacco are brought
near battery. When charging or using a battery in
an enclosed space, always provide ventilation and
shield your eyes.
Keep out of reach of children. Batteries contain
sulphuric acid. Avoid contact with skin, eyes, or
clothing. Also, shield eyes when working near
battery to protect against possible splashing of
acid solution. In case of acid contact with skin,
eyes, or clothing, flush immediately with water for
a minimum of fifteen minutes. If acid is swallowed,
drink large quantities of milk or water, followed by
milk of magnesia, a beaten egg, or vegetable oil.
SEEK MEDICAL AID IMMEDIATELY.
To Jump Start - Negative Ground Battery
WARNING: To avoid any possibility of
injury use particular care when connecting
a booster battery to a discharged battery.
1. Position vehicles so that jump leads will reach,
ensuring that vehicles DO NOT TOUCH,
alternatively a fully charged slave battery may be
positioned on floor adjacent to vehicle.
2. Ensure that ignition and all electrical accessories
are switched off; the parking brake must be
applied and neutral selected on a manual
gearbox; for an automatic gearbox select neutral
(N) or park (P). Connect the jump leads as
follows;
A. Connect one end of first jumper cable to positive
(+) terminal of booster battery.
B. Connect other end of first jumper cable to
positive (+) terminal of discharged battery.
C. Connect one end of second jumper cable to
negative terminal of booster battery.
D. Connect other end of second jumper cable to a
good earth point on the engine, NOT TO
NEGATIVE TERMINAL OF DISCHARGED
BATTERY. Keep jumper lead away from moving
parts, pulleys, drive belts and fan blade
assembly.
WARNING: Making final cable connection
could cause an electrical arc which if
made near battery could cause an
explosion.
3. If booster battery is installed in another vehicle,
start engine and allow to idle.
4. Start engine of vehicle with discharged battery,
following starting procedure in Owners’ Manual.
CAUTION: If vehicle fails to start within a
maximum time of 12 seconds, switch
ignition off and investigate cause. Failing
to follow this instruction could result in
irrepairable damage to catalysts.
5. Remove negative (-) jumper cable from the
engine and then terminal of booster battery.
6. Remove positive (+) jumper cable from positive
terminals of booster battery and discharged
battery.
