Range Rover P38
04
GENERAL SPECIFICATION DATA
NEW RANGE ROVER
16
INFORMATION
BRAKES
Front service brake
Caliper
Lucas Colette, single sided, two piston
..............................................................................
Operation
Power hydraulic, self-adjusting
.........................................................................
Disc
Reverse ventilated, outboard
..................................................................................
Disc diameter
297.2 mm (11.7 in.)
...................................................................
Disc thickness
25 mm (1 in.)
..................................................................
Wear limit
22.0 mm (0.87 in.)
.........................................................................
Disc run out maximum
0.15 mm (0.006 in)
.....................................................
Pad area
64.9 cm
2
(10 in
2
) per pad
..........................................................................
Total swept area
844 cm
2
(130.8 in
2
) per disc
...............................................................
Pad minimum thickness
2 mm (0.08 in.)
...................................................
Rear service brake
Caliper
Lucas Colette,single sided, single piston
..............................................................................
Operation
Power hydraulic, self-adjusting
.........................................................................
Disc
Solid, outboard
..................................................................................
Disc diameter
304.0 mm (12 in.)
...................................................................
Disc thickness
12.6 mm (0.5 in.)
..................................................................
Wear limit
11.7 mm (0.46 in.)
.........................................................................
Disc run out maximum
0.15 mm (0.006 in)
.....................................................
Pad area
34.4 cm
2
(5.33 in
2
) per pad
..........................................................................
Total swept area
798 cm
2
(123.7 in
2
) per disc
...............................................................
Pad minimum thickness
2 mm (0.08 in.)
...................................................
Parking brake
Type
Mechanical-cable operated drum brake on the rear
.................................................................................
of the transfer gearbox output shaft
Drum internal diameter
254 mm (10 in.)
.....................................................
Width
70 mm (2.75 in)
................................................................................
Anti-lock brake system
Manufacturer/type
Wabco/power hydraulic - 4 channel, 4 wheel sensed
............................................................
integrated anti-lock brake system.
ABS control
Microprocessor based ECU
......................................................................
System split
Front/rear
......................................................................
Power source
Electrically driven pump
...................................................................
Power storage
Hydraulic accumulator
..................................................................
Maximum boost pressure
180 bar
.................................................
Reservoir
Built in low fluid warning. Supplies clutch hydraulic
..........................................................................
system
Electronic traction control
Type
Integrated with ABS system
.................................................................................
ETC control
Integrated with ABS ECU
......................................................................
