Range Rover P38
06
TORQUE VALUES
NEW RANGE ROVER
6
DATA, TORQUE & TOOLS
30 - MANIFOLD AND EXHAUST SYSTEM - BMW
DIESEL
* Exhaust manifold to cylinder head nuts
22
.........................
16
Turbocharger to manifold bolts
45
........................................
33
Coolant connecting pipe to front cover bolt
10
......................
7
Front pipe to turbocharger nuts:
- Stage 1
14
..........................................................................
10
- Stage 2 - Slacken 2.5 turns
-
............................................
-
* Inlet manifold to cylinder head nuts
22
...............................
16
Intermediate exhaust pipe flange nuts
25
.............................
18
97MY on:
Tail pipe flange to intermediate pipe flange nuts
25
..............
18
* Tighten progressively working from centre outwards
30 - MANIFOLD AND EXHAUST SYSTEM - V8
PETROL
* Exhaust manifold to cylinder head bolts
55
........................
40
Outer heat shield bolts
8
.....................................................
6
RH shock absorber top mounting bolt
85
..............................
63
Front exhaust pipe to manifold nuts - up to 99MY
50
............
37
Front exhaust pipe to manifold nuts - from 99MY
30
............
22
Front exhaust pipe to intermediate pipe nuts
25
...................
18
+ Gearbox cross member to chassis nuts and bolts
45
........
33
+ Gearbox mounting to cross member flange nuts
45
..........
33
* Inlet manifold to cylinder head bolts:
Ignition coil bracket to inlet manifold nuts
8
.........................
6
Fuel feed pipe to fuel rail union
16
........................................
12
Inlet manifold to cylinder head bolts:
- Stage 1 - Tighten gasket clamp bolts
0.7
.............................
0.5
- Stage 2 - Tighten manifold bolts
10
....................................
7
- Stage 3 - Tighten manifold bolts
50
....................................
37
- Stage 4 - Tighten gasket clamp bolts
17
.............................
12
97 MY on:
Heated oxygen sensor to front pipe
20
.................................
15
LH to RH tail pipe clamps
65
.................................................
48
Tail pipe flange to intermediate pipe flange nuts
25
..............
18
RH tail pipe to LH tail pipe nut
65
..........................................
48
+ New nuts/bolts must be fitted
* Tighten in sequence
