Range Rover P38
77
PANEL REPAIRS
NEW RANGE ROVER
2
PROCEDURES
PANEL REPLACEMENT PROCEDURE
General
This information is designed to explain the basic panel
removal and replacement method. This standard
method may vary slightly from one vehicle to another.
The main criterion in removal and replacement of
body panels is that Land Rover’s original standard is
maintained as far as possible.
Remove Panel
1. Expose resistance spot welds. For those spot
welds which are not obviously visible, use a
rotary drum sander or wire brush fitted to an air
drill, or alternatively a hand held wire brush.
NOTE: In wheel arch areas it may be
necessary to soften underbody coating
using a hot air gun, prior to exposing spot
welds.
2. Cut out welds using a cobalt drill.
3. Alternatively use a clamp-type spot weld
remover.
