Range Rover P38
PANEL REPAIRS
9
SEALING AND CORROSION PROTECTION
APPLICATION EQUIPMENT
SATA Schutz Gun Model UBE
Specifications:
Air consumption
200 litres/min. (7 ft
3
/min.) @ 45 psi
...............................................................
Weight
660grams (23.3oz)
..............................................................................
Manufactured and supplied by:
Sata Gmbh
Minden Industrial Ltd.
16 Greyfriars Road
Moreton Hall
Bury St. Edmunds
Suffolk IP32 7DX
Tel. (01284) 760791
The Sata Schutz Gun is approved for the re-treatment
of vehicle underbody areas with protective coatings as
supplied in 1-litre (1.76pt.), purpose-designed,
’one-way’ containers. The screw thread fitting (female
on the gun) will fit most Schutz-type packs.
Full operating details are supplied with the equipment.
NOTE: Always clean gun after use with the
appropriate solvent.
Sata HKD1 Wax Injection Equipment
The Sata HKD1 is approved by Rover for use in all
cavity wax re-treatment operations. The equipment
comprises a high quality forged gun with 1-litre
capacity pressure feed container, a flexible nylon
lance, 1100 mm (43.3 in) straight steel lance and
hooked wand lance. A quick-change coupling is a
standard fitting to enable lances to be easily
interchanged. The lances each have their own spray
pattern characteristics to suit the type of box section
to be treated.
The Sata HKD1 is covered by a 12 month warranty.
All replacement parts and service are obtainable from
the suppliers.
