Range Rover P38
WIPERS AND WASHERS
3
DESCRIPTION AND OPERATION
WINDSCREEN WIPER AND WASHER OPERATION
The windscreen wipers and washers can only function
with the starter switch turned to positions 1 or 2.
Raise or lower the multi-switch lever to operate the
windscreen wipers only, from position O for each
function, see 84M7013.
Single wipe
Raise the lever to position 1.
The wipers will continue to wipe for as long as the
lever is held in this position.
Intermittent wipe
Lower the lever to position 2.
To vary the delay between wipes rotate the thumb
wheel to the right to increase the delay; to the left to
decrease the delay.
Continuous wipe, slow speed
Lower the lever to position 3.
Continuous wipe, fast speed
Lower the lever to position 4.
NOTE: Functions 1 to 4 will also operate
when the lever is pulled rearwards.
However, in this position the rear screen
intermittent wipe will also function.
Windscreen wash/wipe
Press and hold the lower button (5) at the end of the
lever, see 84M7014.
The washers and wipers will operate for as long as
the button is pressed. When the button is released the
washers stop, but the wipers will continue for a further
three full wipes before parking.
A momentary press of the button will initiate a
programmed wash/wipe cycle.After a short period the
washers will stop and the wipers continue for a further
three full wipes before parking. Moving the lever to
any other front wipe position during the programmed
wash/wipe will cancel the remainder of the
programmed cycle.
If the fluid level in the washer reservoir is low, the
programmed wash/wipe will only operate for as long
as the button is pressed; there will be no timed wash
or additional three wipes.
