SuspensionArms and hubs - continued

Arms and hubs - continued

Arms and hubs - continued
  1. Lower arm and radius arm assembly
  2. Bush - front lower arm
  3. Self-locking bolt
  4. Washer A - front
  5. Bush - front radius arm compliance
  6. Bolt - bush - 14x41 mm
  7. Bolt - bush - 14x83 mm
  8. Washer B - rear
  9. Self-locking nut
  10. Damper fork
  11. Bush - damper fork
  12. Bolt - damper fork
  13. Self-locking nut - M12
  14. Bolt - damper
  15. Anti-roll bar
  16. Anti-roll bar bush
  17. Bush clamp
  18. Bolt - clamp
  19. Spindle bolt - anti-roll bar
  20. Mounting rubber and washer
  21. Self-locking nut - M8
