Engine Compartment LHD (page 2 of 4)

Make

Rover

Model

600 Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition

Section

Relay and control unit locations

ElectricalEngine Compartment LHD · page 2 of 4

A Power window relay

B Radiator fan relay

C Windscreen wiper intermittent relay

D Condenser fan relay

E A/C compressor clutch relay

F A/C diode

G Headlight adjuster unit (KG)

H ABS motor relay

I Engine compartment ABS fuse/relay box

J Test tachometer connector

K Engine compartment fuse/relay box

L Dimmer relay

M Headlight relay

18 Electrical
