Vauxhall Omega B04 · Body Equipment
04 · Body & interior

Assembly Diagram of Co-driver Airbag

Make
Vauxhall
Model
Omega B
Section
Airbag › Description and Operation › Assembly Diagram of Co-driver Airbag
Body EquipmentAssembly Diagram of Co-driver Airbag





Assembly Diagram of Co - driver Airbag



1     Airbag reinforcement

2     Bulkhead, right

3     Bracket, front

4     Hinge bolt

5     Cover, airbag unit

6     Airbag unit

7     Airbag bracket

8     Instrument panel reinforcement

9     Instrument panel



The front bracket (3) is bolted to the bulkhead (2).

The airbag reinforcement (1) is bolted from the rear to the instrument panel reinforcement (8).

Instrument panel (9) bolted to bulkhead (2).

The airbag bracket (7) is bolted to the front bracket (3).

The airbag unit (6) is bolted to the airbag bracket (7).

The airbag unit cover (5) is fastened to the instrument panel reinforcement (8) at the top and to the airbag bracket (7) at the bottom with the hinge bolt (4) and 3 bolts.





Object Number: 2388757  Size: DEFAULT





·    Service



If the airbag system has been deployed in a collision, all brackets and reinforcements must be checked for deformation and cracks, and replaced if necessary.
