Terminal Assignment, Wiring Harness Plug (Airbag)

Terminal Assignment of Wiring Harness Plug

Ter. 1              Squib circuit lead, driver airbag, signal lead

Ter. 2              Squib circuit lead, driver airbag, ground

Ter. 3              Diagnostic lead 1

Ter. 4              Diagnostic lead 2

Ter. 5              Squib circuit lead, co - driver airbag, ground

Ter. 6              Squib circuit lead, co - driver airbag, signal lead

Ter. 7              Ignition, Ter. 15

Ter. 8              Unoccupied

Ter. 9              Telltale

Ter. 10            Ground, Ter. 31

Ter. 14 / 15     Short circuit interruption, driver airbag

Ter. 18 / 19     Short circuit interruption, co - driver airbag

Ter. 22 / 23     Short circuit interruption, telltale

Ter. 24 / 25     Unoccupied
