Airbag (Circuit Diagram): Description and Operation

Circuit Diagram



H 23      System telltale                                                                                               530



K 31       Airbag control unit                                                                                        530 .. 536



S 64       Switch, horn                                                                                                  528 .. 529



U 20      Contact unit                                                                                                   528 .. 532

U 21      Driver airbag                                                                                                 530 .. 532

U 21.1   Squib, driver airbag                                                                                       530 .. 532

U 22      Co - driver airbag                                                                                          534 .. 536

U 22.1   Squib, co - driver airbag                                                                                534 .. 536



XD         Diagnostic plug ALDL, 16 - pin                                                                   534

X 90       Wiring harness plug, instrument panel / airbag control unit, 26 - pin           530 .. 536

X 91       Wiring harness plug, instrument panel / contact unit, 2 - pin                        530 .. 532

X 92       Wiring harness plug, contact unit / driver airbag, 2 - pin                              530 .. 532

X 93       Wiring harness plug, instrument panel / co - driver airbag, 2 - pin               534 .. 536

X 94       Wiring harness plug, contact unit / horn switch, 2 - pin                                528 .. 529

X 95       Wiring harness plug, contact unit / horn switch, 2 - pin                                528 .. 529

Circuit Diagram
