P70 Radio amplifier

Make

Fiat

Model

Idea Factory Service Manual

Year

2003–2012

Section

Various consumers › P70 Radio amplifier

Connectors and pin-outsP70 Radio amplifier

P70 Radio amplifier

1.4 16v, 1.3 JTD 16v

Wiring	Colour
25 REAR	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1.5	H		D97Q	4
2	1.5	M		D97R	4
3	1.5	R		B98	1
4	1.5	M		D97Q	9
5	1.5	MB		D97R	9
7	1.5	HN		C31	9
8		CB		D20	12
