00 Introduction and technical dataFront suspension

Scudo [1997] 16v CF3

Front suspension

Front suspension independent, MacPherson type with lower track control arms connected by means of two flexible bushes to a crossmember.

Offset coil springs and double acting, hydraulic shock absorbers.

Joints with lifetime lubrication

Anti-roll torsion bar

Coil springs

Order number	N.A.
Wire diameter mm	N.A.
Number of effective coils	N.A.
Coil direction	N.A.
Released spring height mm	N.A.
Height under a load of: mm	N.A.
Spring are divided into two categories, identified by markings
yellow (1) springs are loaded to: a height of mm	N.A.
green (1) springs are loaded to: a height of mm	N.A.

(1) Springs of the same type must be fitted.

Dampers

Type, telescopic double-acting	hydraulic
Order number	1307658080
Travel (beginning of damping) mm	186.5
Maximum extension mm	510±2

Original page
