Timing Belt: Specifications (page 15 of 19)
- Make
- Kia
- Model
- Spectra5
- Engine
- L4-2.0L
- Year
- 2005
- Section
- Timing Belt
MaintenanceSpecifications · page 15 of 19
4) Install the spark plug cables.
3. Install the crankshaft sprocket (A).
4. Align the timing marks of the camshaft sprocket (A) and crankshaft sprocket (B) with the No. 1 piston placed at top dead center and its
compression stroke.
