TD5 Defender
AIR CONDITIONING
3
REPAIR
Refit
6. Position bracket to receiver drier and tighten
clamp bolt.
7. Position receiver to chassis and tighten bolts.
8. Remove plugs from A/C pipes.
9. Lubricate new ’O’ rings with refrigerent oil.
10. Fit ’O’rings, position pipes and tighten bolts to 8
Nm (6 lbf.ft) .
11. Recharge A/C system. See Adjustment.
RELAY - TEMPERATURE CONTROL - FROM 02MY
Service repair no - 82.20.40
Remove
1. Remove front speaker from drivers side. See
ELECTRICAL, Repair.
2. Release relay from support bracket.
3. Disconnect multiplug and remove relay.
Refit
4. Connect multiplug to relay and fit relay to
bracket.
5. Fit front speaker. See ELECTRICAL, Repair.
