Discovery II
AIR CONDITIONING
REPAIRS
82-37
Sensor - air temperature
$% 82.20.93
Remove
1. Release 2 quarter turn screws to release fascia
access panel.
2. Lower fascia access panel.
3. Disconnect multiplug from air temperature
sensor.
4. Remove 2 screws securing air temperature
sensor to fascia.
5. Remove air temperature sensor from fascia.
Refit
1. Position air temperature sensor to fascia and
secure with screws.
2. Connect multiplug to air temperature
3. Position and secure fascia access panel with
quarter turn screws.
