Discovery II
FRONT AXLE
54-10
REPAIRS
9. Remove oil seal from axle casing.
Refit
1. Clean drive shaft oil seal recess, oil seal
running surface, wheel hub and swivel hub
mating faces.
2. Lubricate oil seal lip and running surface with
LUBRICANTS AND SEALANTS,
Lubrication.
3. Using tool LRT-54-012 and tool LRT-99-003,
fit new drive shaft oil seal to axle casing.
4. Apply anti-seize compound to wheel hub and
steering knuckle mating faces.
5. Ensure ABS harness is located in cut out in
steering knuckle.
6. Fit drive shaft and wheel hub to axle casing and
align wheel hub with steering knuckle. Fit wheel
hub bolts and tighten to 100 Nm (74 lbf.ft).
7. Connect ABS sensor multiplug and secure
harness to harness bracket and brake hose.
8. Fit front brake disc.
9. Fit road wheel and tighten nuts to 140 Nm (103
lbf.ft).
10. Remove stand(s) and lower vehicle.
11. Check differential oil level.
