Discovery II
WINDOWS
86-5-10 DESCRIPTION AND OPERATION
Rear window motors
There is a rear window motor located in each rear door. The rear window motors are permanent magnet motors with
an integral circuit breaker that provides stall protection.
The rear window switches provide battery voltage and an earth path to the rear window motors. Operating the switch
in the opposite direction reverses the voltage and earth paths at the rear window motor, allowing the motor to run in
the opposing direction.
TestBook cannot monitor the rear window lift motors.
