Discovery II
WIPERS AND WASHERS
REPAIRS
84-27
Jet - washer - headlamp
$% 84.20.08
The procedure to remove the headlamp washer jet
on 03MY vehicles is detailed in the front bumper
finisher job.
EXTERIOR FITTINGS, REPAIRS, Trim
finisher - bumper - front - from 03MY.
Remove
1. Remove retaining screw cover from jet
housing.
2. Remove screw securing jet to bumper.
3. Release jet and withdraw sufficiently to gain
access to washer tube. Disconnect tube from
jet and remove jet.
Refit
1. Connect jet to washer tube, ensuring it is
pushed fully home.
2. Locate jet in bumper, retain with screw and fit
screw cover.
Jet - washer - rear screen
$% 84.30.09
Remove
1. Remove spare wheel.
2. Remove rear screen wiper blade.
3. Release washer jet and washer jet tube from
wiper arm.
4. Release washer jet from washer jet tube and
remove jet.
Refit
1. Fit new washer jet to washer jet tube and fit to
wiper arm.
2. Fit rear screen wiper blade.
3. Fit spare wheel.
