Discovery II
WIPERS AND WASHERS
84-22
REPAIRS
Reservoir - washer - from 03MY
$% 84.10.03
Remove
1. Remove the front bumper assembly.
2. Disconnect multiplug from the headlamp
washer pump.
3. Place a container beneath vehicle to collect any
spillage.
4. Noting fitted position disconnect multiplugs and
washer hoses from the front and rear
windscreen washer pumps.
5. Remove 2 nuts and 2 bolts securing the washer
reservoir to the body.
6. Release washer reservoir from filler neck.
Remove the washer reservoir.
7. Remove and discard the washer reservoir filler
neck seal.
NOTE: Do not carry out further dismantling if
component is removed for access only.
8. Remove washer pumps from washer reservoir
and discard the seals.
Refit
1. Clean washer pump and filler neck seal
recesses.
2. Fit new washer pump and filler neck seals to
the washer reservoir.
3. Fit and secure washer pumps to the washer
reservoir.
4. Fit washer reservoir to the filler neck, fit and
tighten the nuts and bolts.
5. Connect multiplugs and washer hoses to the
windscreen washer pumps.
6. Remove container from beneath the vehicle.
7. Fit the front bumper assembly.
