300Tdi Discovery
57
STEERING
6
REPAIR
Refit
6. Position reservoir, connect feed and return
hoses and tighten clamps to
3 Nm.
7. Fit reservoir in clamp, tighten clamp bolt.
8. Fill reservoir to ’MAX’ mark on dipstick with
power steering fluid.
See LUBRICANTS,
FLUIDS AND CAPACITIES, Information,
Recommended Lubricants and Fluids
9. Fit undertray.
10. Bleed power steering system.
See Power
Steering System - Bleed
POWER STEERING PUMP DRIVE BELT
Service repair no - 57.20.02
NOTE: For details of drive belt remove and
refit.
See ENGINE, Repair, Drive Belt
POWER STEERING PUMP - V8i
Service repair no - 57.20.14
NOTE: The power steering pump is not
serviceable. Fit new pump if worn or
damaged.
Remove
1. Disconnect battery negative lead.
2. Remove drive belt from steering pump.
See
ENGINE, Repair, Drive Belt
3. Remove undertray.
4. Remove fan blades and viscous coupling.
See
COOLING SYSTEM, Repair, Viscous
Coupling, Fan Blades, Pulley and Fan Cowl
5. Position drain tin beneath steering pump.
6. Using a 9 mm Allen key to restrain steering
pump pulley, remove 3 bolts securing pulley to
pump; remove pulley.
