300Tdi Discovery
STEERING
17
REPAIR
3. Bend back tabs on locking washer and remove
drop arm using extractor LRT-57-012. Loosen
drop arm securing nut, but do not remove before
using extractor.
4. Remove nut, discard locking washer.
Refit
5. Centralise steering box.
See Adjustment,
Centralise Steering Box
6. Fit drop arm, align master splines.
7. Fit a new tab washer and drop arm fixing nut.
Tighten to
176 Nm, bend over tab.
8. Fit drag link. Tighten ball joint nut
40 Nm.
STEERING DAMPER
Service repair no - 57.55.21
Remove
1. Site vehicle on a ramp [hoist].
2. Remove fixings at differential case bracket.
3. Remove fixings at track rod bracket.
4. Remove steering damper.
Refit
5. Reverse removal procedure. 1 to 4.
