L322 Range Rover Service Procedures
MANIFOLD AND EXHAUST SYSTEM - V8
30-2-14 REPAIRS
Gasket(s) - exhaust manifold - LH
$% 30.15.17
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Position vehicle on lift.
2. Disconnect battery earth lead.
3. Release clips securing LH and RH pre-catalyst
HO2S harness leads.
4. Release clips securing LH and RH post catalyst
HO2S harness leads.
5. Support weight of exhaust with jack.
6. Remove 4 nuts securing front exhaust rubber
mountings to body.
M30 1093
M30 1094
