LT230Q Transfer Box
TRANSFER BOX
OVERHAUL
49
Neutral warning lamp switch - if fitted
1. Apply Hylosil PL 32 sealant to threads of
switch.
2. Fit washer, fit and tighten switch.
Differential lock warning lamp switch - adjust
1. Move differential lock selector fork to
differential locked position.
2. Connect a 12V test lamp and battery to
differential lock switch.
3. Screw switch in until test lamp is illuminated
then screw switch in a further 1/2 turn; tighten
locknut.
4. Disengage differential lock, check that test
lamp is extinguished.
5. Remove test lamp.
6. Apply sealant from kit to mating face of
differential lock side cover.
7. Fit side cover, fit bolts and tighten to 25 Nm (18
lbf.ft).
