Range Rover P38
07
GENERAL FITTING REMINDERS
NEW RANGE ROVER
6
INFORMATION
FUEL SYSTEM HOSES
CAUTION: All fuel hoses are made up of
two laminations, an armoured rubber outer
sleeve and an inner viton core. If any of
the fuel system hoses have been disconnected, it
is imperative that the internal bore is inspected to
ensure that the viton lining has not become
separated from the amoured outer sleeve. A new
hose must be fitted if separation is evident.
COOLING SYSTEM HOSES
CAUTION: The following precautions
MUST be followed to ensure that integrity
of cooling hoses and their connections to
system components are maintained.
Hose orientation and connection
1. Correct orientation of cooling hoses is important
in ensuring that the hose does not become
fatigued or damaged through contact with
adjacent components.
2. Where ’timing’ marks are provided on the hose
and corresponding connection, these must be
used to ensure correct orientation.
3. Hoses must be pushed fully onto their
connection points. Usually, a moulded form on
the stub pipe provides a positive indicator.
