Range Rover P38
10
MAINTENANCE
NEW RANGE ROVER
4
MAINTENANCE
RENEW FUEL FILTER ELEMENT (DIESEL)
Renew fuel filter.
See FUEL SYSTEM, Repair.
DRAIN WATER FROM FUEL FILTER (DIESEL)
RENEW AIR FILTER ELEMENT AND CLEAN
DRAIN HOLE (DIESEL)
RENEW AIR FILTER ELEMENT AND CLEAN
DRAIN HOLE (V8)
1. Release 4 clips, lift air cleaner cover.
2. Remove air filter element.
3. Fit new element ensuring it locates correctly in
air cleaner body.
RENEW POLLEN FILTERS
Renew pollen filters.
See HEATING AND
VENTILATION, Repair.
RENEW EVAP CANISTER, CHECK EVAPORATIVE
LOSS SYSTEM AND FILLER CAP SEAL (V8)
Renew EVAP canister.
See EMISSION CONTROL,
Repair.
CHECK CONDITION OF ANCILLARY DRIVE
BELT/S (poly V)
Renew drive belts if damaged.
RENEW ANCILLARY DRIVE BELT (POLY V)
Alternator Drive Belt - Renew.
See ELECTRICAL,
Repair.
CHECK/TOP UP AUTOMATIC TRANSMISSION
FLUID - up to 99MY
CAUTION: When replacing the dipstick,
ensure that the handle lugs fully engage
with tube.
NOTE: Check the fluid level only when the
engine and gearbox are cold.
1. Ensure vehicle is level, then select ’P’ (park) and
start the engine.
2. With the engine running at idle speed and both
footbrake and hand brake applied, move the
selector lever to position ’1’ and then back to
position ’P’.
3. Still with the engine running remove dipstick,
wipe using lint free cloth.
4. Reinsert the dipstick fully and withdraw again to
check the level.
5. Check fluid level registers between MAX and
MIN marking on dipstick. For fluid
recommendations.
See LUBRICANTS, FLUIDS
AND CAPACITIES, Information.
CHECK/TOP UP AUTOMATIC TRANSMISSION
FLUID - from 99MY
1. Refer to gearbox drain and refill procedure.
See
AUTOMATIC GEARBOX, Repair.
