Range Rover P38
NAVIGATION SYSTEM
1
REPAIR
NAVIGATION COMPUTER
Service repair no - 86.53.01
Remove
1. Using tool SMD 4091 release clips securing
navigation computer to bracket and pull
computer forward.
2. Disconnect 2 multiplugs from navigation
computer and remove computer.
Refit
3. Connect multiplugs to navigation computer.
4. Fit computer to bracket and secure clips.
