NON ABS AND ABS2E
BRAKE SYSTEM COMPONENTS

1. Servo body
2. Brake pedal
3. Primary piston
4. Primary spring
5. Secondary spring
6. Secondary piston
7. Recuperation seals
8. Supply ports
9. Stop pin
10. Centre valve
11. Hydraulic modulator
12. Calipers – Front
13. Calipers – Rear
14. Piston sleeve
15. Poppet valve
16. Piston top
17. Spring
18. Spring
19. Spring
20. Vent plug
21. Mounting plate
22. Caliper piston
23. Inner brake pad
24. Brake disc
25. Caliper body
26. Guide pins
27. Outer pad
