Replace glass sunroof assembly - L69 (Sliding Roof)

Make

Vauxhall

Model

Astra H

Section

Sliding Roof › Repair Instructions › Replace glass sunroof assembly - L69

Body EquipmentReplace glass sunroof assembly - L69

Replace glass sunroof assembly – L69   Remove 1.   Detach moulded headlining 2.   Detach 4x water drain hoses 3.   Release actuation unit •   Unscrew 16x bolts 4.   Remove actuation unit Note:   2nd mechanic required.   Install 5.   Position sunroof assembly •   Screw in 2x screw Note:   2nd mechanic required! 6.   Attach sunroof assembly •   Tighten 16x bolts 4 Nm •   Attach 4x water drain hoses 7.   Attach moulded headlining

04 Body & interior
