BrakesABS Telltale
Function
The ABS Telltale indicates whether the ABS - 2SH is operating correctly. If the ARS telltale extinguishes approx. 3 sec. after ignition "ON", the ABS - 2SH is operating correctly If the ARS remains illuminated or illuminates while travelling, the ABS - 2SH anti - lock brake system has recognized a fault.
· Service
The ABS telltale can be checked using the TECH 1 actuator test.
|
||
