Circuit Diagram ABS-2SH without/with TC

Circuit Diagram, ABS - 25H without / with TC



F 19       Fuse, ABS                                                                                                     125

P 17       Wheel speed sensor, front left                                                                      130

P 18       Wheel speed sensor, front right                                                                    133

P 1 9      Wheel speed sensor, rear left                                                                       136

P 20       Wheel speed sensor, rear right                                                                     139

U 4        ABS hydraulic modulator, assembly                                                             121.. 148

U 4.1     Relay, pump motor                                                                                        122, 123

U 4.2     Relay, solenoid valves                                                                                  124, 125

U 4, 3    Pump motor                                                                                                   122

U 4.5     Solenoid valve, front left                                                                              129

U 4.6     Solenoid valve, front right                                                                            131

U 4.7     Solenoid valve, rear axle                                                                              133

U 4.8     ABS control unit with / without TC                                                              126.. 148

U 4, 9    Plug, solenoid valves, 6 - pin                                                                        129.. 133



X1          Instrument panel and body, 107 - pin                                                           125.. 128; 140.. 148

X2P       Body and ABS wheel speed sensor, 2 - pin                                                 130.. 140

X4P       Body and ABS hydraulic modulator with / without TC, 4 - pin                    122.. 126

X 25P    Body and ABS hydraulic modulator, 25 - pin                                               127.. 148

XD         Diagnosis, 16 - pin                                                                                        128



Additional for ADS with TC:



S 33       TC switch                                                                                                      147.. 148
