Electrics and Hydraulics Diagram (ABS)
- Make
- Vauxhall
- Model
- Omega B
- Section
- ABS › Description and Operation › Electrics and Hydraulics Diagram
BrakesElectrics and Hydraulics Diagram
|
Electrics and Hydraulics Diagram
1 Wheel speed sensor 2 Wheel brake cylinder 3 Hydraulic modulator 4 Solenoid valves 5 Return pump 6 Brake master cylinder 7 ABS - 2SH control unit
|
|
