70 BodyworkBonnet

BONNET

REMOVING/REFITTING/ADJUSTMENT

  • The bonnet hinge is a single component with the upper door hinge
  1. To remove the bonnet without adversely affecting door adjustment, it is necessary to slacken the screws shown leaving the hinge fastened to the body. (For removing/refitting/adjustment of the bonnet using these screws, see specific paragraph).
  2. For removing the bonnet complete with hinges, refer to the paragraphs concerning "Removing/Refitting Hinges" of the doors and "Adjustment of Doors and Hinges".
Diagram showing bonnet hinge area with arrows indicating adjustment directions and a side view of the car

NOTE: To adjust the bonnet, the catch adjustment pin, damper pads and telescopic props must be installed.
