07 TransmissionTransmission (07.00)
Transmission (07.00)
Manual Transmission (07.03)
Description
The Graziano AM803T transaxle installed to this vehicle incorporates a six speed transmission, with synchromesh on all gears. Gear selection is by a twin cable system (shift and select) operating an integrated bellcrank and H gate.
Cooling
The manual transaxle has an external cooling circuit which operates continuously by a fixed displacement pump driven by the input shaft.
The cooler is mounted at the rear attached to the subframe.
