EngineIntroduction - vacuum air circuit

INTRODUCTION - VACUUM AIR CIRCUIT

1.4 16v

SPECIFICATIONS

The air intake circuit is made up of various components that ensure the correct amount of air is conveyed to the engine under its various service conditions.

1. Cold air intake

2. Air filter assembly

3. Air hose to throttle body

4. Filter element cover
