AIR CONDITIONING - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000 · Climate control system

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C10	Front left earth
C15	Facia earth, driver''s side
D8	Front/air conditioning - heater coupling
G45	Air conditioning/heater controls light	Op. 5020B HEATER CONTROLS
H80	Climate control controls	Op. 5040D AIR CONDITIONING CONTROLS
H81	Climate control fan control	Op. 5040C AIR CONDITIONING CASING AND COMPONENTS
K10	4 stage pressure switch
K10	4 stage pressure switch	Op. 5040B SYSTEM SAFETY CONTROL DEVICES
N85	Passenger compartment ventilation fan	Op. 5020A CASING AND COMPONENTS
N86	Electronic thermostat
O30	Passenger compartment air fan adjustment resistor	Op. 5020A CASING AND COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C10	Front left earth
C15	Facia earth, driver''s side
D8	Front/air conditioning - heater coupling
G45	Air conditioning/heater controls light	Op. 5020B HEATER CONTROLS
H80	Climate control controls	Op. 5040D AIR CONDITIONING CONTROLS
H81	Climate control fan control	Op. 5040C AIR CONDITIONING CASING AND COMPONENTS
K10	4 stage pressure switch
K10	4 stage pressure switch	Op. 5040B SYSTEM SAFETY CONTROL DEVICES
N85	Passenger compartment ventilation fan	Op. 5020A CASING AND COMPONENTS
N86	Electronic thermostat
O30	Passenger compartment air fan adjustment resistor	Op. 5020A CASING AND COMPONENTS
