Central locking - wiring diagram

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Electrically activated devices › Central locking - wiring diagram

Wiring diagrams and electrical functionsCentral locking - wiring diagram

CENTRAL LOCKING - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C30	Left rear earth
D196	Right sliding side door coupling
D197	Right sliding side door coupling
D30	Front left door connection
D31	Front right door connection
D35	Rear left door connection
D36	Rear right door connection
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
D97	Short circuiting coupling
I11	Boot opening switch
I11	Boot opening switch	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I21	Switch on rear door	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M1	Body computer
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
N166	left sliding side door lock geared motor
N167	Right sliding side door lock geared motor
N50	Left front door lock geared motor	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N51	Right front door lock geared motor	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N52	Rear door lock geared motor	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
N55	Left rear door lock geared motor	Op. 7020N SLIDING SIDE DOOR CENTRAL LOCKING
N56	Right rear door lock geared motor	Op. 7020N SLIDING SIDE DOOR CENTRAL LOCKING
N57	Boot lock gearmotor
P93	Aerial for alarm and central locking receiver

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C30	Left rear earth
D196	Right sliding side door coupling
D197	Right sliding side door coupling
D30	Front left door connection
D31	Front right door connection
D35	Rear left door connection
D36	Rear right door connection
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
D97	Short circuiting coupling
I11	Boot opening switch
I11	Boot opening switch	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I21	Switch on rear door	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M1	Body computer
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
N166	left sliding side door lock geared motor
N167	Right sliding side door lock geared motor
N50	Left front door lock geared motor	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N51	Right front door lock geared motor	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N52	Rear door lock geared motor	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
N55	Left rear door lock geared motor	Op. 7020N SLIDING SIDE DOOR CENTRAL LOCKING
N56	Right rear door lock geared motor	Op. 7020N SLIDING SIDE DOOR CENTRAL LOCKING
N57	Boot lock gearmotor
P93	Aerial for alarm and central locking receiver

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Components

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
C030	LEFT REAR EARTH
D30	REAR/DRIVER''S FRONT DOOR COUPLING
D31	REAR/PASSENGER FRONT DOOR COUPLING
D085	TAILGATE/REAR SEAL
D097	SHORT CIRCUITING COUPLING
D196	LEFT SLIDING SIDE DOOR COUPLING
D197	RIGHT SLIDING SIDE DOOR COUPLING
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
I11	BOOT OPENING SWITCH	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I21	SWITCH ON REAR DOOR	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
N50	DRIVER''S FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N51	PASSENGER FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N52	REAR DOOR LOCK GEARED MOTOR	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
N057	BOOT LOCK GEARED MOTOR
N166	LEFT SLIDING SIDE DOOR LOCK GEARED MOTOR	Op. 7020N SLIDING SIDE DOOR CENTRAL LOCKING
N167	RIGHT SLIDING SIDE DOOR LOCK GEARED MOTOR	Op. 7020N SLIDING SIDE DOOR CENTRAL LOCKING
P93	RECEIVER AERIAL FOR ALARM AND CENTRAL LOCKING
