HEATED SEATS - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D69	Seat bridges/rear coupling	Op. 7045D FRONT SEAT TRIM/PADDING
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
O40	Left seat heater

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D69	Seat bridges/rear coupling	Op. 7045D FRONT SEAT TRIM/PADDING
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
O40	Left seat heater

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Components

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
I65	DRIVER''S SEAT HEATING SWITCH	Op. 7045M FRONT SEAT HEATING
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
O40	LEFT SEAT HEATER	Op. 7045M FRONT SEAT HEATING
