Dipped headlamps - wiring diagram

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Exterior lighting › Dipped headlamps - wiring diagram

Wiring diagrams and electrical functionsDipped headlamps - wiring diagram

DIPPED HEADLAMPS - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C10	Front left earth
C15	Facia earth, driver''s side
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
F10	Left headlamp	Op. 5540B HEADLAMPS
F11	Right headlamp	Op. 5540B HEADLAMPS
H5	Stalk unit	Op. 5550A STALK UNIT
H5	Steering column switch unit
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C10	Front left earth
C15	Facia earth, driver''s side
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
F10	Left headlamp	Op. 5540B HEADLAMPS
F11	Right headlamp	Op. 5540B HEADLAMPS
H5	Stalk unit	Op. 5550A STALK UNIT
H5	Steering column switch unit
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
