Fog lights - wiring diagram

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Exterior lighting › Fog lights - wiring diagram

Wiring diagrams and electrical functionsFog lights - wiring diagram

FOG LIGHTS - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C10	Front left earth
C15	Facia earth, driver''s side
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
F10	Left headlamp	Op. 5540B HEADLAMPS
F11	Right headlamp	Op. 5540B HEADLAMPS
H90	Switch control unit	Op. 5505A MULTI-FUNCTION COMPONENTS
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C10	Front left earth
C15	Facia earth, driver''s side
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
F10	Left headlamp	Op. 5540B HEADLAMPS
F11	Right headlamp	Op. 5540B HEADLAMPS
H90	Switch control unit	Op. 5505A MULTI-FUNCTION COMPONENTS
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Components

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C10	LEFT FRONT EARTH
C15	DASHBOARD EARTH, DRIVER''S SIDE
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
F15	LEFT FOG LIGHT	Op. 5540D FOG LIGHTS
F16	RIGHT FOG LIGHT	Op. 5540D FOG LIGHTS
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
H90	SWITCH CONTROL UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
